Fence Semi Trailers
Edit3 Axle High Side Wall Semi Trailer for Grain and Bagged Cargo
Model: KYD-SW-HS
High side wall semi trailer with extended panel height for increased volume capacity. Ideal for lightweight bulk cargo like grain and bagged materials.
Key Technical Specifications
Loading Capacity
40-60 tons
Axle Configuration
3 axles
Model
KYD-SW-HS
Certification
ISO 9001 & CE
Commercial Information
Minimum Order:1 unit
Delivery Time:15-25 working days
Payment Terms:T/T
Warranty:12 months
Product Overview
This specialized high side wall semi trailer maximizes cubic capacity for low-density, high-volume cargo. The taller side panels (up to 1.8m) prevent spillage while allowing full legal payload utilization.
Volume Optimization:
• Side wall height: 1.6m-1.8m (customizable)
• Internal width: 2.45m for standard pallet compatibility
• Smooth interior surface prevents cargo damage
• Optional top rail for tarpaulin attachment
• Rear swing gates or barn doors available
Primary Uses: Grain elevator operations, rice and wheat transport, animal feed distribution, fertilizer and seed delivery, cotton bale hauling.
Complete Technical Specifications
Technical Specifications
| dimensions | 13000x2500x3400mm |
| payload | 60 tons |
| kingpin | 3.5 inch |
| landing gear | 28T two-speed |
| suspension | Mechanical leaf spring |
| brake system | dual-line pneumatic with ABS |
| tires | 12R22.5 x 12pcs |
| side wall height | 1600-1800mm |
| internal width | 2450mm |
| rear door | Swing gate or barn door option |
| floor | flat steel plate |
Key Features & Advantages
Extended side wall height 1.6-1.8m for maximum volume
Smooth interior surface prevents cargo damage
Standard 2.45m internal width for pallet compatibility
Optional top rail for tarpaulin attachment
Rear swing gates or barn doors available
Optimized for low-density high-volume cargo
Applications & Use Cases
Grain elevator operations
Rice and wheat transport
Animal feed distribution
Fertilizer and seed delivery
Cotton bale hauling
Frequently Asked Questions (FAQ)
Q1What side wall heights are available?
Standard 1.6m, with options for 1.4m, 1.6m, and 1.8m heights
Q2Can it carry palletized goods?
Yes, 2.45m internal width accommodates standard Euro and ISO pallets side by side
Q3Is there a rear door option?
Yes, choose between swing gates or barn-style doors for rear access
Q4How is cargo protected from weather?
Optional tarpaulin cover system with top rail attachment points
Ready to Discuss Your Requirements?
Contact our sales team today for customized solutions, competitive pricing, and fast delivery. We respond to all inquiries within 24 hours.
