Edit100 Ton Heavy Equipment Transporter Lowboy Semi Trailer
Model: KYD-LB100
Ultra heavy duty 100 ton lowboy transporter for mining equipment, large cranes, and industrial mega-loads. Engineered for extreme payload requirements.
Key Technical Specifications
Loading Capacity
100 tons
Axle Configuration
4-5 axles
Model
KYD-LB100
Certification
ISO 9001 & CE
Commercial Information
Minimum Order:1 unit
Delivery Time:35-50 working days
Payment Terms:T/T
Warranty:12 months
Product Overview
This ultra heavy-duty lowboy semi trailer is built for the most challenging transport requirements in mining, energy, and infrastructure sectors. With 100 ton payload capacity, it handles the largest mobile equipment safely and efficiently.
Mega-Load Engineering:
• 5x20-ton axles with hydraulic suspension balancing
• Reinforced box-section frame construction
• High-tensile steel (Q690) for critical stress points
• Computer-optimized weight distribution analysis
• Finite element analysis validated design
Mining Industry Proven:
• Hauls 100+ ton mining excavators (CAT 6050, Komatsu PC5500)
• Transports large haul truck bodies and components
• Supports mining expansion and maintenance operations
• Built for harsh mine site road conditions
• Corrosion-resistant coating for longevity
Energy Sector Applications: Mobile crane transport (200-500 ton class), oil rig component hauling, gas turbine delivery, hydroelectric generator parts, nuclear facility component moves (with proper licensing), petrochemical plant module logistics.
Regulatory Compliance: Designed to meet oversize/overweight permit requirements in major markets. Engineering certification packages available for specific country approvals.
Complete Technical Specifications
Technical Specifications
| deck height | 1100mm |
| deck length | 14000mm |
| deck width | 3500mm |
| payload | 100 tons |
| kingpin | 3.5 inch reinforced |
| landing gear | 32T heavy duty |
| suspension | Hydraulic suspension balancing |
| brake system | dual-line pneumatic with ABS and EBS |
| axles | 5x20-ton |
| tires | 12R22.5 x 20pcs |
| frame construction | Reinforced box-section Q690 steel |
| design validation | Finite element analysis certified |
| coating | Corrosion-resistant zinc-rich + polyurethane |
Key Features & Advantages
100 ton payload capacity for mega-load transport
5x20-ton axles with hydraulic suspension balancing
High-tensile Q690 steel for critical stress points
Computer-optimized weight distribution analysis
Finite element analysis validated structural design
Built for harsh mining and construction environments
Applications & Use Cases
Mining excavator transport (100+ ton class)
Large haul truck body and component hauling
Mobile crane transport (200-500 ton class)
Oil rig component logistics
Gas turbine delivery
Hydroelectric generator part transport
Petrochemical plant module hauling
Frequently Asked Questions (FAQ)
Q1What is the maximum payload capacity?
The KYD-LB100 has a rated payload capacity of 100 tons, suitable for the largest mining excavators and industrial equipment
Q2Is it suitable for mine site conditions?
Yes, it is specifically engineered for harsh mine site road conditions with reinforced frame construction, corrosion-resistant coating, and heavy-duty suspension
Q3What engineering certifications are available?
Engineering certification packages are available for specific country approvals including oversize/overweight permit compliance documentation
Q4Can it transport mobile cranes?
Yes, it can transport mobile cranes in the 200-500 ton class when properly configured with appropriate support and tie-down arrangements
