4 Axle Heavy Duty Flatbed Semi Trailer 80 Tons Capacity
Model: KYD-FB60-4A
Heavy duty 4 axle flatbed semi trailer with 60 ton capacity for oversized cargo and heavy equipment transport. Reinforced frame design ensures stability under extreme loads.
Key Technical Specifications
60-80 tons
4 axles
KYD-FB60-4A
ISO 9001 & CE
Commercial Information
Product Overview
Engineered for demanding heavy cargo applications, this 4 axle flatbed semi trailer delivers exceptional performance with 60-70 ton payload capacity. The reinforced chassis and multi-axle configuration provide superior weight distribution and road stability.
Key Advantages:
• Extra-wide deck (2.8m) for oversized cargo accommodation
• 4x13-ton axles with air suspension option
• Enhanced braking system with ABS for safety
• Modular design allows future extensions
• Suitable for steel coils, pipes, machinery, and project cargo
Ideal for: Heavy equipment transport, industrial project logistics, steel mill operations, wind turbine component hauling, bridge construction support.
Complete Technical Specifications
Technical Specifications
| Overall Dimensions | 13500 x 2800 x 1600 mm |
| Payload Capacity | 80 tons |
| Main Beam | Q345B reinforced steel, 550mm height |
| Axle Configuration | 4 x 13T |
| Suspension | Air suspension (mechanical optional) |
| Braking System | dual-line pneumatic with ABS |
| Landing Gear | 28T two-speed heavy-duty |
| King Pin | 3.5" welded type |
| Floor | anti-slip checkered steel plate |
| Twist Locks | 16 sets ISO standard |
| Tires | 12R22.5 tubeless radial, 16 pcs |
| Electrical System | 24V LED lighting, waterproof |
| Paint | Shot blasting SA2.5 + epoxy zinc primer + polyurethane topcoat |
| Deck Width | 2800mm extra-wide |
Key Features & Advantages
Extra-wide deck (2.8m) for oversized cargo accommodation
4x13-ton axles with air suspension option
Enhanced braking system with ABS for maximum safety
Modular design allows future deck extensions
Reinforced cross-members for concentrated load support
Heavy-duty tie-down rings along deck edges
Applications & Use Cases
Heavy equipment and machinery transport
Industrial project logistics and cargo hauling
Steel mill operations and coil transport
Wind turbine component hauling
Bridge construction material support
Frequently Asked Questions (FAQ)
Q1What is the maximum payload of this 4 axle trailer?
Q2Is air suspension available?
Q3Can the deck width be customized?
Q4What is the delivery time?
Ready to Discuss Your Requirements?
Contact our sales team today for customized solutions, competitive pricing, and fast delivery. We respond to all inquiries within 24 hours.
